Diaphragm Dosing Pump are designed for toughjobs where chemicals must be accurately pumped all day long, year round. Engineered materials are used for the wetted end to pump virtually any chemical, from acids to caustics. Even viscous liquids and suspended solids can be metered and pumped with precise accuracy. Price Range: Approx Rs. 25,000 to Rs. 5,00,000 per unit. Additional Information: • Production Capacity: 300 Nos. / Year • Delivery Time: 10-15 Days • Packaging Details: Standard or Wooden Box
Automation Grade - Manual
Power Source - Electric
I Deal In - New Only
Material - SS 304, SS 304L, SS 316, SS 316L, MS, PP, PTFE, ALLOY, PVDF
Country of Origin - Made in India
Phase - Single Phase, Three Phase
Model Name/Number - UMBL
Suction Delivery - Flooded
Max Flow Rate - 10000 LPH to 75000 LPH
Motor Horsepower - 0.5 HP to 15 HP
Standard Accessories - Coupling, Coupling Guard, Electric Motor, MS Fabricated Base Plate
Maximum Pressure - 500 Kg/cm2
Usage/Application - For Dosing Molten Sulfur, Molten Wax and Handling liquid at high temperature
Motor Phase - Single Phase & Three Phase
Pump Type - Plunger Type
Frequency - 50 Hz
Discharge Pressure - 500 Kg/cm2
Motor Speed - 1000 RPM, 1500 RPM, 3000 RPM
Capacity - 75000 LPH
Minimum Order Quantity - 1 Unit
Maximum Head - 5000 Meter
Color - Epoxy Coated Color
Model Number - UMBL-10, UMBL-20, UMBL-25, UMBL-30, UMBL-40, UMBL-60, UMBL-80
Electrical Ratings - IP 55
Maximum Discharge Flow - 75000 LPH
Head - 5000 Meter
Accessories Included - Yes
Voltage - 230V & 415V
Temperature Rating - 70 DegreeC to 350 DegreeC
Surface Finish - Auto Finish
