Specifications: Product Application Shampoo. Sachets dimensions To be provided Sealing Through pneumatically activated jaws. Feeding systems Piston filler with pump. Packing Film Continuous heat sealable laminated film in roll form with eye marks. Sachet Orientation Front Collection. Film draw mechanism Through Clutch and brake. PLC Yes, Mitsubishi/ Messang make. AC Drive Yes, Delta/ schnider make Micro view Yes, standard make Pneumatic components Standard make. Temperature Controller PID Based, standard make. Registration on Film (Photo mark) Yes. Electrical motors GE / Crompton. Contact Parts SS- 316 Cladding SS- 304 Electrical components Standard quality. Optional Attachment: (Inclusive) Embossing attachment, Embossing digits for printing Date of Manufacturing, Expiry Date & Batch No. (On Vertical sealing area)
Temperature Controller - PID Based
Compressed Air Required - 6 CFM @ 6 Bar
Sealing Type - 4 Sided sealing
Main Motor Power - 1 HP
Machine Packing Speed - Approx. 30- 35 sachets per minute per track
Voltage - 415 V
No of Tracks - Single track
Filling Range - 10 ml
Power Consumption - Approx 2.5 kW
