Spirometer is a hand-held equipment for checking lung conditions, adopts the infrared mode for measuring relative items, and is applicable for hospital, clinique for routine test. Get best price of Contec SP10 Pulmonary Function Test Machine. Product Description: • Rechargeable lithium battery with battery power display • Automatic power off when there is no operation in one minute • Forced Vital Capacity [FVC], Forced Expired Volume in one second [FEV], the ratio of FEV1 and FVC [FEV1%]. Peak expiratory flow (PEF), 25% flow of the FVC [FEF25], 75% flow of the FVC [FRF75] and average flow between 25% & 75% of the FVC [FRF2575] can be measured and display. • Besides, the testee condition can be shown by the ratio of the measured value and the predicted value. • Display: Flow rate -Volume chart, volume —time chart • Data memory, delete, upload and review • Trend chart display • Scaling [Calibration] • Information prompts when volume or flow goes beyond the limits • Ratio of FEV1 and FVC can be measured • Software interface and trend chart display • Battery backup: 4 hours Technical Features: • Max Volume: 10L • Flow Range: 1L/s~16L/s • Volume accuracy: ±3% or 0.05L [Whichever is greater] • Flow accuracy: ±10% or 0.3L/s [Whichever is greater] • The highest resistance to flow within the measurement is 6Pa/L/s, and this resistance may occur at 14L/s Optional: • Wireless Interface Through Bluetooth
Power Supply - DC3.7V rechargeable lithium battery
Touchscreen - No
Printer - No
Synonyms - Spirometry Machine, Diagnostic Spirometer
Mode - Automatic
Real Time Testing - Yes
Software Support - Yes
Display resolution: - 160 x 128 pixels
Minimum Order Quantity - 1 Piece
Type - Hand-held Spirometer
Volume range - 0~10L
Flow Range - 1 L/S ~16L/S
USB Port - Yes
Working current - 60 mA
Tests Performed - FVC,FEV1,FEV1%,PEF,FEF25,FEF75,FEF2575
Volume Accuracy - +-3% or 0.05L
Display Mode - 1.8'' TFT colour screen,LED blacklight
Model Name/No. - SP10
Usage/Application - Hospital, Clinic, Diagnostic Center
Flow Accuracy - +-10% or +-0.3L/s
Brand - Contec
Weight - 150g
Bluetooth - Yes
Wireless Testing - Yes
Dimensions - 97mmx 89mmx 36mm
