Features: • Drilling diameter from 0.3mm to 3mm. (Optional Max. Φ 6.0mm) • The maximum depth ratio could be 300:1. • Blind holes can also be drilled, Precision (hole straightness) is less than 0.04 mm. • Can drill on oblique and curved surface directly. • Fast processing speed and low consumption. • Can use water as coolant, low cost and no pollution. Additional Information: • Pay Mode Terms: L/C (Letter of Credit), T/T (Bank Transfer) • Port of Dispatch: ANY PORT OF INDIA • Production Capacity: 100 SETS • Delivery Time: READY STOCK OR 2-4 WEEKS
Working Table Size - 360x480 mm
Dimension - 1060x950x1700 mm
Spindle Stroke W-Axis - 300 mm
Power - 4.0 kW
Brand - Fostex
Weight - 600 kg
Max. Working Current - 30 A
Stroke X-Y - 300x400 mm
Voltage - 415 V
