Specifications: Product application Chocolates Quantity / Pouch One unit / Pouch. Product Dimension To be conveyed in mm. In-Feeding System Manual feeding through in-feed conveyor with Pushers. (Approx. 2 meter long). Pouch / Sealing Type Pillow type / Center sealing. Laminate Any continuous heat sealable laminated roll Drive A. C. Drive (1 H. P, Standard Make) Photocell with Control Panel Analog Amp Meter Digital with control panel. Adjustable Forming Plate Yes Horizontal Track for Smooth running Yes Control Panel with SSR Yes
Temperature Controller - PID based
Steel Grade - SS 202, SS 304
Motor Power - 1 HP
Covering Material - SS
Output Conveyor - 1 Meter long
Speed - Approx 45-60 Pouches per Minute
Main Body Material - MS
Net Weight - Approx 500 Kg
Phase - 3 Phase
Voltage - 220V
Gear Motor - 3 kW
Frequency - 50 Hz
