Standard Specifications: Model Full Volume 200L 300L 500L 1000L 1500L 2000L Turning Speed 46rpm 46rpm 46rpm 46rpm 46rpm 46rpm Mixing Vessel 1.5mm 1.5mm 1.5mm 1.5mm 3mm 4mm Wall Plate 6mm 8mm 8mm 8mm 8mm 12mm Main Shaft 57*6 76*6 76*8 89*8 102*8 114*10 Mixing Blade 6mm 6mm 6mm 8mm 10mm 12mm Whole Length 1400 1530 1700 2000 2400 2600 Whole Width 900 1000 1200 1300 1400 1500 Total Height 1450 1550 1700 1960 2050 2200 Total Weight 250KGS 350KGS 500KGS 700KGS 1000KGS 1300KGS Total Power 4KW 5.5KW 7.5KW 11KW 15KW 22KW Power Supply 3 P AC208-415V 50/60HZ
Material of Construction(Contact) - SS 304
Brand - The Scientific Apparatus
Electricity Connection - Three Phase
Operation Mode - Automatic
Power Consumption - 5 Kwh
Capacity - 1000 kg.
Type of Machine - Blower Pulverizer
Motor Power - 5 HP
