Salient Features: • Screwed Female Ends to IS 554 / BS 21 / ISO 7. • Screwed in Bonnet, Integral Seat. • Permits flow in one direction and closes automatically if the flow reverses. • Metal Disc is mushroom shaped with spherical seating surface. • Meant for Horizontal Lines Only. • Disc is guided in Body as well as in Bonnet. • Heavy Pattern. • Also available with metal to metal seating
Model Number - 1011
Brand - Zoloto
Valve Size - 8 mm
Pressure - Shell : 35 kg/cm2g (500 psig)
Working Temperature - 80 Degree C (Max)
Material - Bronze Brass
