Salient Features: • Screwed Female Ends to IS 554 / BS 21 / ISO7. • Screwed in Bonnet, Integral Seat. • Permits flow in one direction and closes automatically if the flow reverses. • Metal Disc is mushroom shaped with spherical seating surface. • Meant for Horizontal Lines only. • Disc is guided in Body as well as in Bonnet. • Medium Pattern. • Also available with metal to metal seating.
Model Number - 1010
Brand - Zoloto
Temperature - 80 Degree C (Max)
Valve Size - 8 mm
Pressure - 20 kg/cm2g (285 psig) sell
Material - Brass/Bronze
